MAIN SPINDLE DIRECTION :
TURNING DIAMETERS:
TURNING LENGTHS:
MAXIMUM SWING :
CHUCK DIAMETER :
BAR CAPACITY
HEADSTOCK - SPINDLE 1
NOSE :
SPEED :
BORE :
|
Horizontal
NOMINAL:8.070" MAX:13.780"
NOMINAL:21.65" MAX:21.65"
22.050 "
STANDARD:10.000" MAX:10.000"
STANDARD:2.790 "
A1-8
35 - 3500 RPM
3.340 "
|
TOOLING
TYPE
MAX. NUMBER OF TOOLS
TOOL SHANK SIZE (inches):
SQUARE
ROUND
FLOOR LAYOUT:
MACHINE NET WEIGHT:
|
PRIMARY
TURRET
12
1.000 "
1.500 "
* LENGTH: 127 "
* WIDTH: 65 "
* HEIGHT: 77 "
10340 pounds
|
